500V-600W Adjustable Single Output AC-DC Switching Power Supply 50/60Hz High Precision Voltage Options 88-89% Efficiency 1 Year

Specializing in high-power regulated power supplies for 15 years with a professional production factory of 10,000 square meters. Product exports are highly convenient for global clients.

Product Name: DC Switching Power Supply
Application: Widely used in various DC application sites such as power electronics, electroplating, water treatment, battery charging, new energy maintenance, etc.
Protection: Overcurrent, Overvoltage, Overheat, Short Circuit Protection
Features: High stability and reliability
Warranty: 1 year
Weight: Approximately 2KG

Technical Specifications

Product Name	DC Switching Power Supply	Operating Relative Humidity	20%~88%
Power Rating	600W	Application Scenarios	Power electronics, electroplating, water treatment, battery charging, new energy maintenance, and other DC application fields
Input Voltage	Single-phase 220V±10%, 50-60HZ 110V±10%, 50-60HZ	Protection Functions	Overcurrent, overvoltage, overheating, short-circuit protection
Output Voltage	12V 15V 24V 30V 36V 48V 50V 60V 72V 80V 90V 110V 150V 220V 300V 400V 500V	Product Features	High stability, high reliability
Output Current	Selected power/selected voltage	Warranty Period	1 Year
Power Conversion Type	AC-DC	Product Weight	Approximately 2KG
Efficiency	>88-89%	Carton Dimensions	26013570 mm
Output Voltage Accuracy	±1%

Product Instructions

1. Pre-Power Check Check for any damage incurred during transit (e.g. loose screws, abnormal appearance, shaken power cords/terminals, or signs of dampness) and address them promptly before powering on.
2. Power Connection & Safety The local power switch controls the internal auxiliary power supply. For safety, install an air switch at the power input terminal to control power input. Ensure the ground wire and input power wires are connected accurately according to the rear panel label, and confirm that the connected input voltage matches the manual specifications.
3. Temperature-Controlled Cooling Fan The cooling fan is temperature-controlled and starts when the internal temperature exceeds the starting threshold. Speed variations based on output voltage and current are normal. Ensure fan inlets and outlets are never blocked during operation.
4. Overheat Protection If the internal temperature reaches the overheat threshold, the machine will shut down automatically to prevent damage, and will resume operations once the temperature drops.
5. Environmental Precautions Avoid using the equipment in environments with abnormal levels of dust, acid, corrosive gases, direct sunlight, rain, or severe vibrations.
6. Regular Maintenance Regularly clean the dust inside the unit using dry compressed air to extend the machine's lifespan. Do not open the casing unless qualified, and avoid damaging internal components.
7. Long-Term Storage Store idle equipment in a dry, ventilated room. If stored for over 6 months, power on and run the device for at least 30 minutes to maintain component health.
8. Load Connection Warning Only connect to the powered load equipment when the initial power-on test is normal and free of errors.
9. Troubleshooting & Handling If any abnormalities occur, cut off the power switch immediately. Check internal/external connections for tightness and correctness, and ensure switches and knobs are positioned accurately. Do not attempt self-repair or disassemble the casing without professional expertise, as high voltages inside present an electric shock hazard.

Frequently Asked Questions

Is there overvoltage, overcurrent, overheating, or short circuit protection?

Yes, this switching power supply is fully equipped with overvoltage, overcurrent, overheating, and short circuit protection.

Is there reverse protection?

Reverse protection is not included by default but can be added as an optional customization.

Can it be used at full power for a long time?

No, for long-term continuous operation, it is recommended to run the power supply below 80% capacity to ensure optimal stability and lifespan.

Is it convenient to adjust voltage and current?

Yes, it is highly convenient. You can adjust both voltage and current easily using the dual knobs on the panel.

Is this high-power power supply isolated?

Yes, our high-power power supplies feature a fully isolated design for enhanced safety and performance.

What is the voltage regulation range?

The voltage regulation range starts from 1V.
