Specializing in high-power regulated power supplies for over 15 years with a professional production facility of 10,000 square meters. A recognized honest enterprise unit and excellent after-sales service provider.
| Product Name | DC Switching Power Supply | Operating Relative Humidity | 20%~88% |
| Power Rating | 500W | Application Scenarios | Power electronics, electroplating, water treatment, battery charging, new energy maintenance, and other DC application fields |
| Input Voltage | Single-phase 220V±10% 50-60HZ / 110V±10% 50-60HZ | Protection Functions | Overcurrent, overvoltage, overheating, short-circuit protection |
| Output Voltage | 12V, 15V, 24V, 30V, 36V, 48V, 50V, 60V, 72V, 80V, 90V, 110V, 150V, 220V, 300V, 400V | Product Features | High stability, high reliability |
| Output Current | Selected power / Selected voltage | Warranty Period | 1 Year |
| Power Conversion Type | AC-DC | Product Weight | Approximately 1.5 kg |
| Efficiency | >88-89% | Carton Dimensions | 255 × 125 × 65 mm |
| Output Voltage Accuracy | ±1% | - | - |
Q: Is there overvoltage, overcurrent, overheating, or short circuit protection?
A: Yes, the unit comes equipped with overcurrent, overvoltage, overheating, and short-circuit protection features.
Q: Can it be used at full power for a long time?
A: No, the power supply needs to be used with excess capacity. Power load below 80% is recommended for long-term usage.
Q: Is it convenient to adjust voltage and current?
A: Yes, the voltage and current can be easily adjusted with dual control knobs.
Q: Is the high-power power supply isolated?
A: Yes, our products features fully isolated power supply designs.
Q: What is the voltage regulation range?
A: The voltage regulation starts from 1V.
Q: Is the power supply sufficient?
A: Yes, it provides sufficient rated output power.
