Technical Specifications

Product Instructions

• 1
  Before powering on, check the stored and transported switch power supply. Any damage during transportation should be checked, such as whether the screws are loose, whether the appearance is abnormal, whether the power cord and terminal are shaken off, and whether they are damp. If any of the above phenomena occur, they should be dealt with in a timely manner.
• 2
  The local power switch controls the auxiliary power supply inside the machine. For safety reasons, please add an air switch to the power input terminal to control the power input. Connect the ground wire and input power wire according to the label on the rear panel to confirm that they are connected correctly. Pay attention to whether the voltage of the connected input power supply is consistent with the voltage indicated in the manual.
• 3
  The cooling fan is temperature controlled. When the temperature inside the machine exceeds the starting temperature control point of the fan, the fan will start. The fan speed varies with the output voltage and current, which is normal. When working, please make sure not to block the inlet and outlet of the fan.
• 4
  When the temperature inside the machine reaches the threshold for overheating shutdown, the machine will automatically stop working to ensure that it is not damaged. When the temperature drops slightly, it will automatically start to resume work.
• 5
  When using power equipment, the dust, acid, corrosive gases, or substances in the air should not exceed normal levels. Severe vibration, bumps, rain, and direct sunlight should be avoided as much as possible.
• 6
  It is recommended to regularly perform dust removal, which can greatly improve the service life and reliability of power equipment (dry compressed air can be used for dust removal. Note that there is high pressure inside; do not open the casing and be careful not to damage internal components).
• 7
  When the power equipment is idle for a long time, it should be stored in a dry and ventilated room. If the storage time exceeds 6 months, the power supply equipment should be powered on and operated for more than half an hour.
• 8
  Warning: Only connect to the powered load equipment when the power-on test is normal and error-free.
• 9
  Handling of Malfunctions: If abnormal operation is found after turning on the machine, the power switch of the stabilized power supply should be cut off immediately. Check the internal and external connections carefully for correctness and check the connecting screws for looseness. Verify all switches and knobs are in the correct position. If there are problems that are difficult to handle, do not unscrew the screws or remove the casing without authorization. Due to high voltage inside the machine, do not attempt to repair it yourself without professional knowledge and equipment to avoid electric shock accidents.
